BREVICOMIN

?

6,8-Dioxabicyclo[3.2.1]octane, 7-ethyl-5-methyl-, (1R-exo)-

exo-Brevicomin

(+)-exo-brevicomin

60018-04-4

?

[1] Bellas, TE; Brownlee, EG;? Silverstrein, RM Tetrahedron ? 25 , 5149 .

In this scheme, the base, B:, could be C=O, R-O-R, R-OH, H₂O or the conjugate base of the acid catalyst endo-Brevicomin(+)-endo-Brevicomin, the pheromone of the bark beetles such as western pine beetle、southern pine beetle and mountain pine beetle, was synthesized using lipase-catalyzed asymmetric acetylation as the key step.

"A New Synthesis of (3S, 4R)-8-Nonene-3,4-diol, the Key Intermediate for the Synthesis of (+)-endo-Brevicomin"
　　K. Mori and H. Kiyota, Liebigs Annalen der Chemie, 1992, 989-992 (1992).

NMR

Reference(s)

Stewart, T.E., Plummer, E.L., McCandless, L.L., West, J.R., and Silverstein, R.M. 1977. J. Chem. Ecol. 3:27-43.

Francke, W., Schröder, F., Philipp, P., Meyer, H., Sinnwell, V., anf Gries, G. 1996. Bioorg. Med. Chem. 4:363-374. .......................................................................................................  (+)-exo-brevicomin (2), (1R,5S,7R)-7-ethyl-5-methyl-6,8-dioxabicyclo[3.2.1]octane, http://dx.doi.org/10.1590/S0103-50532002000200015  Article Asymmetric Synthesis of exo-Isobrevicomin and exo-Brevicominvia Conjugated Addition of Primary Alkyl Iodides to a,b-Unsaturated Ketones Andréa L. de Sousa and Inês S. Resck* Instituto de Química, Universidade de Brasília, CP 4478, 70919-970, Brasília - DF, Brazil * e-mail: isresck@unb.br http://www.scielo.br/scielo.php?script=sci_arttext&pid=S0103-50532002000200015 Using the same conditions as above, compound 2 was prepared as a pale liquid (0.12 g, 96%); IR nmax/cm-11461, 1382, 1239, 1174, 1033 (film); 1H NMR (400 MHz, CDCl3) d 0.90 (t, J 7.4 Hz, 3H), 1.40 (s, 3H), 1.41-1.94 (m, 8H), 3.92 (t, J 6.5 Hz, 1H), 4.12 (s large, 1H); 13C NMR (50 MHz, CDCl3) d 9.8, 17.2, 25.1, 28.0, 28.6, 35.0, 78.3, 81.2, 107.7; GC/EIMS (70 eV) m/z 156 (M+, 8%), 114 (100), 98 (46), 85 (96). ................................................................... An efficient γ-epimerization of γ-vinyl-γ-butyrolactone is studied under palladium catalysis. The building blocks derived there in are used in an efficient stereoselective synthesis of (+)-exo- and (+)-endo-brevicomins. http://pubs.rsc.org/en/content/articlelanding/2014/ra/c4ra00814f#!divAbstract ......................................................................... Note | Regular issue | Vol 55, No. 4, 2001, pp.781-784 Published online:  DOI: 10.3987/COM-01-9161 ■ A Concise Synthesis of (-)-endo-Brevicomin John K. Gallos,* Loukia C. Kyradjoglou, and Theocharis V. Koftis *Department of Chemistry, Aristotle University of Thessaloniki, Thessaloniki 540 06, Greece Abstract A new method for the synthesis of (-)-endo-brevicomin from D-ribose in four steps is reported. PDF (139KB)

...................................................

DRUG APPROVALS BY DR ANTHONY MELVIN CRASTO .....FOR BLOG HOME CLICK HERE

Join me on Linkedin

Join me on Facebook FACEBOOK

Join me on twitter

Join me on google plus Googleplus

 amcrasto@gmail.com

Magnetic anisotropy

Protons attached to simple vinyl groups resonate from 4.5 to 7 ppm. Part of the explanation is that sp²carbons are more electronegative, since the bond contains more s character (33% compared to 25%). The carbon s orbital pulls bonds in tighter, away from the attached protons.

By itself this does not explain such a large shift. A greater effect is magnetic anisotropy. Anisotropy also explains why acetylenic protons are found from 3 to 2 ppm, since we would expect them to be higher than vinyl protons based on hybridisation alone. It also explains why the chemical shift of benzylic protons is so high.

An anisotropic field is a field that is not isotropic. An isotropic field either has a uniform density, or a spherically symmetric density distribution.

When aromatic molecules are placed in a magnetic field, mobile pi electrons in it are induced to circulate around, which itself produces a new magnetic field - an anisotropic one.

The benzylic protons are in the region deshielded by the induced anisotropic field. Protons above the ring would be shielded by the induced anisotropic field, as shown empirically in these molecules:

A similar effect is found in pi bonds, with the current moving around the internuclear axis:

For double bonds, this deshields the end protons. For triple bonds it shields them:

So an aromatic molecule in an NMR machine experiences three different magnetic fields. The external field of the machine, the diamagnetic shielding from valence electrons (an isotropic field that counteracts the external field) and any anisotropic fields induced by currents induced by the external field. The chemical shift of a proton environment depends on the net effect of these.

These opens a lot of questions such as:

Why do magnetic fields induce current in some systems but not others?

Why does the moving current itself create another magnetic field?

Why are pi electrons more mobile?

Why do pi electrons in triple bonds induce in the opposite direction to double bonds?

And so on. The answers, if any, are found in physics textbooks. Spectroscopy textbooks will just summarize what happens and what the effects are.
