Thursday, 31 October 2013
Cinacalcet Hydrochloride spectral data
IR (KBr) (cm–1): 3447, 2964, 1587, 800, 776.
MS: m/z = 358.3 [M + H] +.
1H NMR (CDCl3): δ 1.98 (d, J = 6.7 Hz, 3H), 2.2–2.35 (m, 2H), 2.46–2.60 (m, 2H), 2.55–2.85 (m, 2H), 5.10–5.25 (m, 1H), 7.16–7.26 (m, 3H), 7.31–7.33 (d, J = 7.4 Hz 1H), 7.54–7.65 (m, 3H), 7.88–7.97 (m, 3H), 8.23 (d, J = 7.2 Hz,1H).
13C NMR (DMSO-d6): δ 19.99 (CH3), 27.01 (CH2), 31.50 (CH2), 44.65 (CH2), 52.05 (CH), 122.58, 122.69, 122.73, 124.42, 124.74, 124.67, 125.50, 126.10, 126.88, 128.83, 128.89, 129.32, 130.28, 132.39, 133.32, 134.10, 142.25.
http://pubs.acs.org/doi/full/10.1021/op300164y
........................................................
next set
IR (KBr): 3427 (broad, –NH–), 2951, 2797, 2750, 2712, 1587, 1450, 1327, 1165, 1128, 1072, 798, 775 cm−1;
1H NMR (DMSO-d6/TMS) δ 1.67 (d, J = 6.6, 3H, –CH3), 1.99 (quintet, 2H, –CH2), 2.70 (m, 2H, –CH2), 2.93 (m, 2H, –CH2), 5.30 (q, 1H, –CH), 7.46–7.61 (m, 7H, ArH), 7.95–8.03 (m, 3H, ArH), 8.23 (d, J = 8.0, 1H, ArH), 9.36 (s, 1H, –NH) and 10.04 (s, 1H, HCl);
13C NMR (DMSO-d6/TMS) δ 142.61, 134.48, 133.70, 132.80, 130.64, 129.74, 129.58,129.28, 127.29, 126.54, 125.90, 125.08, 124.67, 123.16, 122.98, 52.37, 45.04, 31.84, 27.44, 20.30;
MS m/z: 358 [M + 1]+.
http://www.beilstein-journals.org/bjoc/single/articleFullText.htm?publicId=1860-5397-8-158
...........................
IR (KBr) cm−1: 3436, 2962, 2797, 1587, 1450, 1379, 1327, 1166, 1129, 797, 774, 746;
MS: m/z = 358.79 [M + H] +;
1H NMR (400 MHz, DMSO-d6): δ = 1.67−1.69 (d, 3H), 1.97−2.02 (m, 2H), 2.67−2.69 (t, 4H), 5.27 (q, 1H), 7.44−7.46 (m, 4H), 7.54−7.61 (m, 3H), 7.93−7.99 (m, 2H), 8.026−8.08 (d, J = 7.2 Hz, 1H), 8.20−8.23 (d, J = 7.2 Hz, 1H), 9.46 (s, 1H), 10.17 (s, 1H);
13C NMR (100 MHz, DMSO-d6): δ = 20.49 (CH3), 27.50 (CH2), 32.02 (CH2), 45.18 (CH2), 52.60 (CH), 123.06, 123..23, 123.26, 124.94, 125.17, 125.21 (CF3), 126.0, 126.60, 127.39, 129.35, 129.39, 129.82, 130.79, 132.88, 133.83, 134.58, 142.75;
Anal. Calcd for C22H23NF3Cl: C, 67.09; H, 5.84; N, 3.55; Found: C, 66.92; H, 5.68; N, 3.58.
http://pubs.acs.org/doi/full/10.1021/op200016a
Wednesday, 23 October 2013
RABEPRAZOLE SPECTRAL DATA
SPECTRAL DATA FOR RABEPRAZOLE SODIUM
EP 1869015 B1
IR Spectra (KBr, cm-1): 3382, 2927, 1583, 1462, 1384, 1298, 1269, 1190, 1157, 1093, 1018, 745.
H NMR Spectra [200 M Hz, CD3OD] δ (ppm): 8.23 – 8.25 (1H, d, ArH); 7.57 – 7.62 (2H, m, ArH); 7.0 – 7.09 (2H, m, ArH); 6.87 – 6.90 (1H, d, ArH); 4.57 – 4.63 (2H, d, O=S-CH2-Ar); 4.0 – 4.1 (2H, t, -O-CH2-CH2-); 3.49 – 3.55 (2H, t, -CH2-O-CH3); 3.31 (3H, s, -OCH3); 2.1 (3H, s, Ar-CH3); 1.96 – 2.0 (2H, t, -CH2-CH2-CH2-).
.......................................................
1H NMR (300 MHz, DMSO-d6) δ (ppm): 8.26-8.24 (d, 1H); 7.48-7.44 (m, 2H); 6.92-6.87 (m, 3H); 4.70-4.66 (d, 1H); 4.45-4.41 (d, 1H); 4.09-4.05 (t, 2H); 3.48-3.44 (t, 2H); 3.23 (s, 3H); 2.14 (s, 3H); 1.99-1.93 (q, 2H).
US 8143409 B2
...........................................................
ONE MORE SOURCE FOR SODIUM RABEPRAZOLE DATA http://www.asianpharmaonline.org/ajpr/3_ajpr_1_1_2011.pdf
IR (KBr, cm-1) 3047 (Ar-H), 2881(Ali-H), 1583 (aromatic
C=C), 1298 (C-N), 1093 (C-O arylalkylether),1027 (S-O,sulphoxide), 745 (Ar-H bending);
MS( ESI)+ve: 382(M++Na);
1H NMR (400MHz, DMSO-d6:
8.44 (d, J=5.6
Hz, 1H), 7.64-7.66 (m, 2H), 7.08-7.10 (m, 3H), 4.60-4.86
(dd, J=13.6, 2H), 4.25 (t, J=6.4 Hz, 2H), 3.64 (t, J=6.4Hz,
2H), 3.40 (s, 3H), 2.31 (s, 3H), 2.13 (qn, J=6.4, 2H).
13CNMR (100 MHz, DMDO-d6) 162.67, 154.68, 150.35,
147.69, 121.40, 119.79, 117.38, 110.49, 106.27, 68.31,
65.09, 57.95, 36.25, 28.68, 10.36.
.......................................................
1H NMR (CDCl3
+DMSO) of Rabeprazole sodium (1): δ 2.1 (m, 2H –CH2-), 2.2 (s, 3H, -
CH3), 3.3 (s, 3H, -OCH3), 3.6 (t, 2H, -OCH2-), 4.1 (t, 2H,-CH2-OCH3), 4.5 (d, Ha, -CH2-
pyridine), 4.7 (d, Hb, -CH2-pyridine), 6.6 (d, 1H, 1H-pyridine), 7.1-7.6 (m, 4H, Ar-H),
8.2 (d, 1H, pyridine). http://rasayanjournal.co.in/vol-1/issue-1/21.pdf
.....
http://www.jcbsc.org/journal/Paper/Vol_2_I_3_2012/A14.pdf ...........GET IR, NMR GRAPHS FOR RABEPRAZOLE SODIUM HERE
.....................................................................
......................................................................
SPECTRAL DATA FOR RABEPRAZOLE (WITHOUT SODIUM)
IR (KBr, cm-1) 3064 (Ar-H), 2898(Ali-H), 1581 (aromatic
C=C), 1300 (C-N), 1095 (C-O arylalkylether),1060 (S-O,
sulphoxide), 753 (Ar-H bending);
MS( ESI)+ve: 360(M++1);
1H NMR (400MHz, DMSO-d6: 12.98 (brs, NH),8.28 (d, J=5.6 Hz, 1H), 7.69-7.61 (m, 3H), 6.70 (d, 2H),4.69-4.82 (dd, J=13.6, 2H), 4.05 (t, J=6.4 Hz, 2H), 3.51 (t,J=6.4Hz, 2H), 3.38 (s, 3H), 2.13 (s, 3H), 2.05 (qn, J=6.4,2H).
13C NMR (100 MHz, DMDO-d6)
163.68, 153.14,149.12, 148.22, 122.87, 119.74, 117.40, 110.50, 106.19,
68.74, 65.12, 58.75, 36.27, 29.21, 11.05.
READ
http://jocpr.com/vol4-iss1-2012/JCPR-2012-4-1-130-139.pdf
http://www.asianpharmaonline.org/ajpr/3_ajpr_1_1_2011.pdf
http://www.ncbi.nlm.nih.gov/pubmed/17945453
http://www.jcbsc.org/journal/Paper/Vol_2_I_3_2012/A14.pdf
http://rasayanjournal.co.in/vol-1/issue-1/21.pdf
