EFAVIRENZ
Spectrum Plot
Fig . 1H NMR spectrum of C14H9ClF3NO2 in CDCL3 at 400 MHz.Shifts
| Index | Name | Shift (ppm) |
|---|---|---|
| 24 | H2 | 6.912 |
| 22 | H3 | 7.513 |
| 18 | H4 | 8.406 |
| 1 | H9 | 0.541 |
| 3 | H8 | 0.607 |
| 5 | H5 | 1.350 |
| 9 | H7 | 0.623 |
| 8 | H6 | 0.535 |
Couplings
| Index 1 | Index 2 | Coupling (Hz) |
|---|---|---|
| 1 | 3 | -4.50 |
| 1 | 5 | 6.15 |
| 1 | 8 | 9.00 |
| 1 | 9 | 6.39 |
| 3 | 5 | 8.95 |
| 3 | 8 | 6.35 |
| 3 | 9 | 9.00 |
| 5 | 8 | 6.03 |
| 5 | 9 | 8.96 |
| 8 | 9 | -4.50 |
| 14 | 15 | 160.00 |
| 14 | 16 | 160.00 |
| 15 | 16 | 160.00 |
| 18 | 22 | 1.70 |
| 18 | 24 | 0.60 |
| 22 | 24 | 7.50 |
PAPER
Correia et al. have published a three-step flow synthesis of rac-Effavirenz. This short synthetic route begins with cryogenic trifluoroacetylation of 1,4-dichlorobenzene. After quench and removal of morpholine using silica gel, this intermediate could either be isolated, or the product stream could be used directly in the next alkynylation step. Nucleophilic addition of lithium cyclopropylacetylide to the trifluoroacetate gave the propargyl alcohol intermediate in 90% yield in under 2 min residence time. This reaction was temperature-sensitive, and low temperatures were required to minimize decomposition. Again silica gel proved effective in the quench of the reaction. However, residual alkyne and other byproducts were difficult to remove. Thus, isolation of this intermediate was performed to minimize the impact of impurities on the final copper catalyzed cyanate installation/cyclization step to afford Effavirenz. Optimization of this step in batch mode for both copper source and ligand identified Cu(NO3)2 and CyDMEDA in a 1:4 molar ratio (20 mol % and 80 mol %, respectively) produced the product in 60% yield. Adaptation of this procedure to flow conditions resulted in poor conversion due to slow in situ reduction of the Cu(II) to Cu(I). Thus, a packed bed reactor of NaOCN and Cu(0) was used. Under these conditions, the ligand and catalyst loading could be reduced without compromising yield. Due to solubility limitations of Cu(NO3)2, Cu(OTf)2 was used with CyDMEDA in 1:2 molar ratio (5 mol % and 10 mol % loading, respectively). Under these optimized conditions, rac-Effavirenz was obtained in 62% isolated yield in reaction time of 1 h. This three-step process provides 45% overall yield of rac-Effavirenz and represents the shortest synthesis of this HIV drug reported to date
1H NMR (400 MHz, CDCl3, ppm) δ9.45 (s, 1H), 7.49 (s,
1H), 7.35 (dd, J = 8.5, 1.5 Hz, 1H), 6.86 (d, J = 8.5 Hz, 1H), 1.43-1.36
(m, 1H); 0.93-0.85 (m, 4H);
13C NMR (100 MHz, CDCl3, ppm) δ 149.2, 133.2, 131.7,
129.2, 127.8, 122.1 (q, JC-F = 286 Hz), 116.3, 115.1, 95.9, 79.6 (q,
JC-F = 35 Hz), 66.1, 8.8, 0.6;
19F NMR (376 MHz, CDCl3, ppm) δ -80.98.
1 T. J. Connolly; A. W.-Y Chan; Z. Ding; M. R. Ghosh;
X. Shi; J. Ren, E. Hansen; R. Farr; M. MacEwan; A. Alimardanov; et al,
PCT Int. Appl. WO 2009012201 A2 20090122, 2009.
2 (a) Z. Dai, X. Long, B. Luo, A. Kulesza, J.
Reichwagen, Y. Guo, (Lonza Ltd), PCT Int. Appl. WO2012097510, 2012; (b)
D. D. Christ; J. A. Markwalder; J. M. Fortunak; S. S. Ko; A. E. Mutlib;
R. L. Parsons; M. Patel; S. P. Seitz, PCT Int. Appl. WO 9814436 A1
19980409, 1998 (c) C. A. Correia; D. T. McQuade; P. H. Seeberger, Adv.
Synth. Catal. 2013, 355, 3517−3521.
SUPP INFO
J. Braz. Chem. Soc. vol.24 no.4 São Paulo Apr. 2013
http://dx.doi.org/10.5935/0103-5053.20130071
http://www.scielo.br/scielo.php?script=sci_arttext&pid=S0103-50532013000400007PAPER
http://jpharmsci.org/article/S0022-3549(15)00007-6/abstract
/////////////////////
